Crane Bodies

  • 134 Aluminum Crane Body
  CAPTIVATOR I CAPTIVATOR II CAPTIVATOR III

Crane Tower 10,000 - 25,000 ft/lbs up to 40,000 ft/lbs 40,000 - 70,000 ft/lbs
Body Matrl. 12 & 14 Ga. Satin-Coat 12 & 14 Ga. Satin-Coat 12 & 14 Ga. Satin-Coat
Body Length 108" - 60 CA 134" - 84 CA 156" - 108 CA
Body Height 48" 48" 60"
Compt. Depth 21" 21" 22"
Compt. Door Matrl. Double Panel Aluminum Double Panel Aluminum Double Panel Aluminum
Handles & Hinges Stainless Steel Stainless Steel Stainless Steel
Rear Bumper Tubular Type Tubular Type Tubular Type
Cargo Floor 3/16' Steel Checker Plate 3/16' Steel Checker Plate 3/16' Steel Checker Plate
Light Kit CMVSS/FMVSS Compliant CMVSS/FMVSS Compliant CMVSS/FMVSS Compliant
Paint PPG - 1 Year Warranty PPG - 1 Year Warranty PPG - 1 Year Warranty
Chassis Requirements 15,000 LB GVWR (min) 19,000 LB GVWR (min) 27,500 LB GVWR (min)
Standard Features:
  • Automotive Grade Door Seals
  • Gas Shock Type Door Holders
  • Stainless Steel Fastening Hardware
  • Integral Rear Wheel Panels for Added Rigidity
  • Rubber Fenderette on Rear Wheel Panels
  • Full Length Drip Trough - Both Side
  • Adjustable Galvanized Shelves
  • Manual Out and Down Outriggers
  • Crane Compartment Drip Tray
  • Undercoating of Body Understructure
  • 2 Part Primer / 2 Part Paint System
  • Four D-style Tie-down Rings in Cargo Floor
  • 1 Year Parts and Labour Warranty
  • 5 Year Structural Warranty
Options Available: Call your local distributor for a full range of options.
  • Service Tool Packages
  • Work Bench Bumpers
  • 60" Raised Verticals Complete with Overlapping Doors
  • Hydraulic Outriggers
  • Various Cargo Control Options
